Matrix Audio TS-1 Streaming DAC & Headphone Amplifier

Matrix Audio TS-1 Streaming DAC & Headphone Amplifier

$2,499.00 USD
$2,499.00 USD
Sale Sold out
Shipping calculated at checkout.

The Versatile Master

Matrix Audio proudly presents the TS-1, a new-generation all-in-one solution for headphone and active monitor audiophiles. Adhering to the core philosophy of "simplifying complexity", the TS-1 seamlessly integrates a streamer, DAC and headphone amplifier into one compact device. Pair it with your favorite headphones or active speakers, and you'll have a high-quality Hi-Fi system ready to go. Whether you’re a digital audio guy seeking convenience or a discerning audiophile with picky ears for sound quality, the TS-1 offers a one-stop solution that strips away the unnecessary and brings music back to its pure essence.

Focused on Experience

Powered by the Hi-Fi streaming hardware platform from the Matrix Audio M Series, the TS-1 delivers a significant leap in performance. Its upgraded display and the continuously evolving MA Player Hi-Fi Streaming OS, paired with the MA Remote App, provide seamless compatibility with both iOS and Android devices. Whether using a smartphone or tablet, you'll experience an effortlessly smooth and intuitive user experience.

Unlimited Resources at Your Fingertips

Access an extensive library of high-resolution music, including TIDAL, Qobuz, HIGHRESAUDIO and internet radio - all seamlessly integrated into one device.

Support streaming protocols including Roon Ready, Audirvana, TIDAL Connect, Qobuz Connect, Spotify Conncet, AirPlay2, QPlay and UPnP/DLNA.

Specifications

Digital Input

COAXIAL & OPTICAL

PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

DSD 2.8MHz (DoP)
HDMI ARC PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
USB Audio

PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz, 705.6kHz, 768kHz

DSD 2.8MHz, 5.6MHz, 11.2MHz (DoP)

DSD 2.8MHz, 5.6MHz, 11.2MHz, 22.4MHz (Native)

Aux In

SNR

 100dB A-weighting

THD+N

 < 0.004%@1k,<0.004%@20Hz-20kHz

Frequency Response

 20Hz-20kHz ±0.1 -3dB@40kHz

Crosstalk

 >-105dB

MAX Input Level

 2.1VRMS

Line Out

XLR

SNR：123dB A-weighting

THD+N：< 0.00018%@1k, < 0.00022%@20Hz-20kHz

Frequency Response：20Hz-20kHz ±0.1 -3dB@80kHz

Crosstalk：>-140dB

Output Level：4.5VRMS @ 0dB / 0~4.5VRMS Adjustable
RCA

SNR：120dB A-weighting

THD+N：< 0.00020%@1k,<0.00022%@20Hz-20kHz

Frequency Respons：20Hz-20kHz ±0.1 -3dB@80kHz

Crosstalk：> -120dB

Output Level：2.2VRMS @ 0dB / 0~2.2VRMS Adjustable
SUB

Cutoff Frequency：150Hz@-3dB

Output Level：2.2VRMS @ 0dB / 0~2.2VRMS Adjustable

Headphone Output

4.4mm Blanced

SNR：119dB A-weighting

THD+N：< 0.0004%@20Hz-20kHz 4VRMS

Frequency Response：20Hz-20kHz ±0.5 -3dB@22kHz

Output Impedance：< 2Ω

Output Power：1000mW@33Ω, 1000mW@300Ω, 500mW@600Ω, 1%THD

Gain：+12dB
6.35mm Unbalanced

SNR：116dB A-weighting

THD+N：< 0.0004%@20Hz-20kHz 2VRMS

Frequency Response：20Hz-20kHz ±0.5 -3dB@22kHz

Output Impedance：< 1Ω

Output Power：1400mW@33Ω, 250mW@300Ω, 130mW@600Ω, 1%THD

Gain：+12dB

Network

LAN

 10/100/1000 Mbps
Wi-Fi 2.4 GHz / 5 GHz

USB

2 x USB 3.0

The USB port provides a maximum power of 5V/1A.

The USB port works with devices which conform to the USB mass storage standard and supports FAT, FAT32, exFAT, and NTFS file formats, but is not guaranteed to be compatible with all storage devices.

MA Player

Controller app MA Remote App

Local Playback

Format Supported：MP3、WMA、WAV、AIF、AIFC、AIFF、AAC、FLAC、OGG、APE、ALAC、M4A、DSF、DFF、CUE、ISO

PCM  16-24Bit/44.1kHz、48kHz、88.2kHz、96kHz、176.4kHz、192kHz、352.8kHz、384kHz、705.6kHz、768kHz

DSD  2.82MHz, 3.07MHz, 5.64MHz, 6.14MHz, 11.29MHz, 12.29MHz, 22.58MHz, 24.58MHz
Roon Ready

PCM  16-24 Bit /44.1 kHz、48kHz、88.2kHz、96kHz、176.4kHz、192kHz、352.8kHz、384kHz、705.6kHz、768kHz

DSD  2.82MHz, 5.64MHz, 11.29MHz, 22.58MHz
QQ Music

The audio specs depend on the service provider
AirPlay 2 The audio specs depend on the service provider
DLNA/UPnP The audio specs depend on the service provider
TIDAL Connect The audio specs depend on the service provider

Qobuz Connect

 The audio specs depend on the service provider
Spotify Connect The audio specs depend on the service provider
vTuner The audio specs depend on the service provider
Radio Paradise The audio specs depend on the service provider

Trigger

Trigger in

 DC 6-12V<10mA

Trigger out

 DC 12V/50mA MAX

Storage Extension

M.2 2280 2260 2242 NVMe PCIe SSD slot

SSD supporting PCIe 3.0/4.0/5.0 standards，The maximum power specification provided by the expansion slot is DC 3.3V3A.

Power

 AC input

Wide voltage switching power supply

Power Voltage: AC 100V-240V 50/60Hz

Standby Power Consumption: < 5W

MAX Power Consumption: < 35W

DC input

External power voltage: DC 12V ±10%

External power wattage: Larger than 36W

Power plug: Outer diameter 5.5mm; inner diameter 2.1mm (+ for inner, - for outer)

Weight & Size

Weight

2.89kg (6.37 pounds)



Dimension

Width: 280 mm (11.02 inches)

Depth: 210 mm (8.27 inches)

Height: 82 mm (3.23 inches)
