Lumin P1 Mini

Lumin P1 Mini

$5,500.00 USD
$5,500.00 USD
Sale Sold out
Shipping calculated at checkout.
Color: Silver

Versatility built In

Builds on the success of the multi-award-winning LUMIN P1 by packing as much of the componentry and flexibility as possible into a new compact chassis.

Why LUMIN P1 Mini

Just like its bigger brother, P1 Mini is designed to be used as a streamer, a DAC, a pre-amplifier or all three!

With 5 analogue and digital inputs, a linear power supply and many other components taken from flagship players, LUMIN P1 Mini packs incredible versatility and value into its new slim chassis.

Main features

  • Five inputs including USB, HDMI, SPDIF and Analogue
  • HDMI with stereo input + AV Passthrough & ARC
  • Dual DAC ES9028PRO
  • DSD512 & PCM384
  • Femto Clock System with precision FPGA distribution
  • New internal toroidal linear power supply
  • Dual Network with Optical Fibre Network support
  • Leedh Processing lossless volume control


5 digital & analogue inputs

Versatile enough for any audio or video stereo system:

USB

  • Industry-leading XMOS USB audio controller
  • Native DSD512 and PCM384 compatible
  • Windows 10 & Mac OS compatibility

Analogue

  • Stereo analogue input
  • LEEDH volume processing
  • Passthrough function for home cinema integration with custom naming functionaity

SPDIF Optical & RCA

  • DoP64 / 192 kHz 24-bit compatible
  • TOSLINK & SPDIF (RCA)

HDMI

  • HDMI 2.0 Specification compatible
  • Supports 2.0 PCM audio decoding
  • HDR, Dolby Vision, Dolby Atmos, DTS passthrough
  • ARC compatible output
  • ARC CEC volume and mute control

X1 Heritage

LUMIN P1 Mini takes many flagship features from the outstanding LUMIN X1:

Fibre Networking

A world-first on X1 and now featured on many LUMIN models, optical networking provides complete isolation from network noise. Additionally, dual network ports mean that you can connect LUMIN L2 or a NAS directly to P1 Mini.

Femto Clocking System

P1 Mini includes dual Femto crystal oscillators and our proprietary FPGA clock distribution system first debuted in X1.



Included Remote Control

A tactile infrared remote control allows easy change of input, volume adjustment, playlist navigation and more.

The exceptionally well-constructed acrylic and zinc LUMIN remote is made in Austria and is entirely Roon Ready.

LUMIN P1 Mini has a built-in infrared receiver and is compatible with universal remote controls, phones and automation systems.

Flexible setup options

Use as a streamer, a DAC, a pre-amplifier or all three!

Idea 1 - Streaming DAC

LUMIN P1 Mini can be used like all other LUMIN players. With its DSD512/PCM384 support, Femto Clock System, Fibre Networking, toroidal power supply, and Leedh Processing, it's packed with incredible components.

Idea 2 - Hi-Fi Hub

Connect all your stereo sources to LUMIN P1 Mini and attach a power amplifier and you've got everything you need for an incredible music system.

Idea 3 - 2-channel TV System

No need for an AV Receiver. Simply attach your HDMI sources to your TV and P1 Mini to your TV. With HDMI ARC, all your audio comes through your main speakers.

Specification

P1 Mini Specification highlights

  • Network playback:

    • Up to DSD512
    • Up to 384 kHz, 16–32-bit, Stereo
    • MQA Full Decoding

  • Upsampling rates & bit depths:

    • DSD256 upsampling option for all files
    • PCM 384kHz upsampling option for all files

  • Digital Input:

    • USB:
      • USB Audio Class 2 Compatible
      • WINDOWS 10 (Release 1703 or above) / Mac OSX or above
      • DoP 128 support
      • PCM 44.1–384 kHz, 16 / 32-bit, Stereo
    • OPTICAL/SPDIF:
      • PCM 44.1 kHz–192 kHz, 16–24-bit
      • DSD64 (DoP64, DSD over PCM)
    • HDMI:
      • PCM 2.0 Audio support
      • 4K Video Passthrough

  • Digital Output:

    • USB:
      • Native DSD512 support
      • PCM 44.1–384 kHz, 16–32-bit, Stereo
    • BNC SPDIF:
      • PCM 44.1 kHz–192 kHz, 16–24-bit
      • DSD64 (DoP64, DSD over PCM)
    • HDMI:(HDMI Passthrough and ARC support)
      • PCM 2.0 Audio support
      • 4K Video Passthrough
      • ARC (Audio Return Channel) support
      • ARC CEC volume and mute control

  • Analogue Input:

    • RCA Stereo x1

  • Analog Output:

    • Dual ESS SABRE32 ES9028Pro DAC chips
    • Fully balanced layout with high-quality components
    • Femto Clock System with precision FPGA distribution

  • Optical Network:

    • Industry-standard Gigabit SFP
    • 1000Base-T Gigabit Ethernet
    • Adapter may be needed for your particular switch/cables
    • Use simultaneously with RJ45 (e.g. connect one to router and one to LUMIN L1 or NAS)

  • Power Supply:

    • Internal toroidal linear
    • Low-noise linear regulator

  • Physical:

    • Finish:

      • Black anodised aluminium
      • Raw anodised aluminium

      Lumin (solid aluminium chassis):

      • 400mm (W), 314mm (D), 77mm (H), 7kg
