Credo EV Reference 1202

We offer modernism and simplicity in the the design of our products. With attention to detail we select materials and define textures. In a Credo speaker you’ll find several very unique features and designs, developed and implemented over many years. We always focused on the highest goal in speaker-design, to reproduce all kinds of music and genres, without compromise.

So the paper-cone, symmetrical drive mid-woofer is accompanied by a 1“ tweeter. The mid-woofers sliced- cone prevents effectively cone breakups, so it is playing from 33 Hz and blending over gently to the tweeter, protected by a high-pass filter. As always with Credo Audio speakers, we achieved linear impedance and a very good efficiency, making it an easy load for amplifiers.

Technical Specifications

• Tweeter: 1 x 1“ Coated textile, neodymium magnet, symmetrical drive motor
• Mid-Woofer: 2 x 5.5“ sliced paper cone, large ferrite magnet symmetrical-drive
• Tuning: Bass reflex (back)
• Crossover: 2-way proprietary filter-design
• Frequency response: 37 Hz – 20 kHz, +/- 3dB
• Roll-off: 36 Hz -2dB, 33 Hz -10dB
• Sensitivity: 86.6 dB @ 2.83V @ 1m
• Linear impedance: nominal 4 Ω, min. 2.1 Ω @ 40 Hz; max. 10.4 Ω @ 1.2 kHz
• Recommended amplifier: 50 W RMS
• Weight: 20.0 kg p.p. without packing
• Size:(HxDxW): 123.4 cm x 22 cm x 18cm
• Including the “isolation-base”
• Hand-crafted by Credo Audio Switzerland
